LM2577 Adjustable Step-up Power Converter Module DC-DC
|
|
#P01319
|
|
|
|
|
|
|
|
Stock:
|
|
Shipping Fee:[Select your city]
|
|
|
|
|
|
|
QTY:
|
|
|
26%
OFF
26%
OFF
26%
OFF
26%
OFF
26%
OFF
Net Weight: 11g
Size: 4.1 x 2.2 x 1.1cm(L x W x H) (Approx)
Color: Blue
Wide Input voltage: 3V-30V
Output Voltage: 4-35V (Adjustable)
Output current: rated current 3A MAX (
Heat-sink Needed)
If you need its output power greater than 15W, please add with heat-sink
Conversion efficiency: Up to 92% (output
voltage higher, the higher the efficiency)
Switching Frequency: 50KHz
Rectifier: Non-Synchronous Rectification
Short circuit protection: current limiting, since the recovery
Operating temperature: Industrial grade (-40°C
to +85 °C) (output power 10W or less)
Full load temperature rise: 40
Load regulation:±
0.5%
Voltage regulation:±0.5%
|
