Net Weight: 669g

Size: Approx 19.8x 9.8 x 4.2cm.
Shell Material: Metal case / Aluminum base.
AC input voltage range: Switch control 85-132VAC/170-264VAC 47-63Hz.
Input current: 4.5A/115V,2.5A/230V.
Output voltage: 0～24V Manual regulation.
AC inrush current: Cold-start current 25A/115V,50A/230V.
Leakage current: <3.5mA/240VAC.
DC adjustable range: +/-15% rated output voltage.
Over load protection: 105-135% hiccup mode, auto-recovery.
Over-voltage protection: 115-135% Cut off the output, auto-recovery.
Over-temp protection: Rectifier≥105C Cut off the output, auto-recovery.
Setup rise hold up time: 200ms 100ms 20ms.
Withstand voltage: I/P-O/P:1.5KvAC; 1minute I/P-FG:1.5KvAC 1minute; O/P-FG:0.5KvAC 1minute.
Working temperature/ humidity: －20?C～+60?C,20%～90%RH.
High efficiency, high reliability, low cost.
100% full load burn-in test.
Over current, over voltage, short circuit and overheat protections.
Low output ripple and yawp.
Widely used in Industrial automation, LED display, communications, etc.
Safety Compliance: CE.
