Net Weight: 268g

Color: Black
Size:11 x 9.5 x 4.8cm(LxWxH)
Cold-end compensation tolerance: ±2℃（can be modified by software in 0~50℃）
Resolution: 14 bit
Sampling cycle: 0.5 Sec
Output, alarm and self-tuning can be indicated by: LED
Relay output: contact capacity 250V AC 3A (resistive load)
Alarm function output: 1 way
Contact capacity of output: 250V AC 3A (resistive load)
Setting value (SV): identical to measuring range (PV)
Proportional band (P): 0~full range (ON/OFF control when set to 0)
Integral time (I): 0~3600 sec (No integral action when set to 0)
Derivative time (D): 0~3600 sec (No derivative action when set to 0)
Heat-reset proportional cycle: 1~100 sec
Detective temperature range：0 to 400°C
Insulation resistance: >50M ohm(500V DC)
Insulation resistance: 1500V AC/min
Power Consumption: 10 VA
Service environment: 0~50?C

Process value (PV), Setting value (SV).

PIN control (including ON/OFF, step-type PID and continuous PID).
Self-tuning control.
environment with no corrosive gas 30~85% RH.
