Net Weight: 186g

Color: Black
Material: Plastic
Size: Approx.14cm(L) x 9cm(W) x 2.4cm(H)
Rated Charge Current: 10A
Rated Discharge Current:10A
System Voltage: 12V/24V Auto
Max Solar Panel Voltage: 41V
Over Load Protection: <130%(maintain for 60s), <160%(maitain for 5S),over-load(immediately shut down)
Self-consume: <6mA
Charge Circuit Voltage Drop: <0.2V
Discharge Circuit Voltage Drop: <0.1V
Equalize Charging Voltage: 14.8V
Bulk Charging Voltage: 14.5V
Acceptance Voltage (PWM):14.2V
Float Charging Voltage: 13.8V
Charge Return Voltage: 13.2V
Discharge Stop Voltage: 11.2V
Discharge Return Voltage: 12.6V
Temperature Compensation: N/S
Operating Temperature: -20℃~+65℃

Full LED status indication: State of Charge(SOC) Red-Flat Battery: Amber-Low charge: Green- good charge: Green Flashing- Full Charge
Note: Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures. Thank you for your understanding
Overcharging protection.
Can be used for all panels.
Overdischarging protection.
Short and Open Circuit protection.
Full specification available if required.
Fail Safe and cannot be damaged by accidental wiring mistakes.
Advanced design with simple plug and play technology. No need for complicated adjustments.
